Frey CP-400 / CP-400P

CP-400 is a premium visual acuity device offering test capabilities high above standards known from use of chart projectors. The device provides many additional features like low vision AMD optotypes, video playback capability, test reporting, spatial frequency and color contrasting testing.

Please fill out the form below for pricing information.






    Category: Manufacturer:

    Description

    RICH SET OF AVAILABLE OPTOTYPE CHARTS

    Multiple test charts are available including letters charts, number charts, symbol charts. CP-400 provides multiple chart display models and scales to allow the user to select the best method for the test procedure.

    COLOR VISION TESTING

    CP-400 has built-in color vision charts allowing the verification of patients’ color recognition abilities.

    CONTRAST SENSITIVITY TESTING

    The contrast sensitivity testing can be performed on CP-400 using optotypes presented at different contrast levels. For more demanding customers sinusoidal bar grading test can be used.

    PATIENT EDUCATION MODULE

    The patient education module of CP-400 provides users to store educational pictures and videos in the memory of the device,  which can be used for explaining eye disorders of the patient.

    TEST REPORTS

    With help of remote control, user may record the results of the patient’s test. At the end of the test, the procedure of the report can be created and stored in device memory in .pdf format. The report can be transferred to an external computer with the use of a USB memory stick or via a WLAN connection.

    USER DEFINED TEST SEQUENCES

    For users willing to standardize their test procedures CP-400 provides a programming function. Up to 3 programs can be defined by the user and then started with just one button click on the remote control.

    AUTOMATED PHOROPTER COMMUNICATION

    CP-400 can communicate wirelessly with many available on the market automated phoropters. This feature allows users to extend the functionality of their existing phoropter systems by functionality not available from chart projectors.

    WIRELESS CONNECTIVITY OPTION

    Wireless communication is a feature available with optional USB WiFi module. It allows communication with CP-400 chart panel in the computer network and access test reports and educational materials stored on the device.
